| 型號 | model | FAG-900A |
| 袋型 | Bagtype | 1.M形編織袋(雙面覆膜) 2.一字形編織袋(雙面覆膜) |
| 包裝范圍 | Packing range (kg) | 5~25 |
| 包裝速度(bag/h) | Packing speed (bag/h) | 600~900 * |
| 稱重精度 | Weighing precision | 士0.1% |
| 包裝袋規格長X寬 | Bag specifications (mm)L xW | (480~780) X (240~370) (覆膜編織袋) |
| 環境溫度 | Ambient temperature | 0~40°C |
| 電源,耗電 | Power supply, power consumption | AC380V 50Hz, 12KW |
| 氣源,耗氣 | Gas source, gas consumption | 0.5~0.7MPa, 12Nm3/h |
| 外形尺寸長X寬X高 | Overall dimension (mm) L xWxH | 4050X 2959X 3095 |
*取決于包裝物料的具體特性和包裝規格
Depend on the specific characteristics of packaging materials and packaging specifications. ①:1. M-shaped woven bag (coated on both sides),2. In-line woven bag (covered on both sides),3. Plastic portable woven bag (coated on both sides) 16②:1. M-shaped woven bag (coated on both sides),2. In-line woven bag (covered on both sides)
| 型號 | model | FAG-900A |
| 袋型 | Bagtype | 1.M形編織袋(雙面覆膜) 2.一字形編織袋(雙面覆膜) |
| 包裝范圍 | Packing range (kg) | 5~25 |
| 包裝速度(bag/h) | Packing speed (bag/h) | 600~900 * |
| 稱重精度 | Weighing precision | 士0.1% |
| 包裝袋規格長X寬 | Bag specifications (mm)L xW | (480~780) X (240~370) (覆膜編織袋) |
| 環境溫度 | Ambient temperature | 0~40°C |
| 電源,耗電 | Power supply, power consumption | AC380V 50Hz, 12KW |
| 氣源,耗氣 | Gas source, gas consumption | 0.5~0.7MPa, 12Nm3/h |
| 外形尺寸長X寬X高 | Overall dimension (mm) L xWxH | 4050X 2959X 3095 |
*取決于包裝物料的具體特性和包裝規格
Depend on the specific characteristics of packaging materials and packaging specifications. ①:1. M-shaped woven bag (coated on both sides),2. In-line woven bag (covered on both sides),3. Plastic portable woven bag (coated on both sides) 16②:1. M-shaped woven bag (coated on both sides),2. In-line woven bag (covered on both sides)
